Wuxi Zerru Technology Co., Ltd
Brand: zerru
Transportation: Ocean,Land,Air
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF
ZGD-03 Sanitary Grade Filter Bag fully meets and is recognized for use in the food and beverage industry. The filter bag is sewn with materials that fully meet the requirements of the food industry, ensuring no problems in food applications. This Bag Filter is part of the Sanitary grade filter bag category, designed specifically for the stringent hygiene and safety standards of these sectors。
The Extended long life filter bag, such as the BPOEX series from Pall Corporation, provides outstanding performance and is known for its ability to hold at least twice the amount of contaminants as a standard felt bag. This feature reduces waste volumes and bag changes, making it ideal for applications like automotive coatings, chemicals, resins, and edible oils.
For applications requiring resistance to a wide range of chemicals and high-temperature tolerance, the PTFE filter bag stands out. Commonly known as Teflon® filter bags, they are made from polytetrafluoroethylene and are known for their chemical inertness, excellent thermal stability, and low friction coefficient. These characteristics make the PTFE filter bag suitable for filtration applications involving aggressive gases and high-temperature environments.
In summary, the ZGD-03 sanitary grade filter bag is tailored for the food and beverage industry, the Extended long life filter bag offers superior dirt handling capacity, and the PTFE filter bag is ideal for chemically resistant and high-temperature applications. Each of these filter bags plays a crucial role in ensuring the quality and safety of filtered fluids across various industries.
The filter material fibers are not easy to fall off, reducing the impact of hair removal on the filtration effect
Independent third-party certified filter bags comply with EC and FDA requirements
Multi layer filter bag, fully welded construction eliminates leakage from the needle hole
Strict monitoring of production eliminates secondary pollution during production, storage, and processing
Separate packaging to prevent contamination during transportation, storage, and installation
Special handling and storage methods to ensure that packaging is not contaminated
| Zhuo Nuo bag filter model | |
| ① 过滤器型号缩写 Abbreviation of filter model | |
| ②设备壳体材料滤袋数量 Number of filter bags for equipment shell material S-stainless steel C-carbon steel P-duplex steel N-nickel alloy H-Hastelloy alloy | |
| CO Carbon Steel Lined PO CP Carbon Steel Lined PP CE Carbon Steel Lined PTFE | |
| The number represents the number of filter bags. For example: 3=3 bag filter | |
| ③ Flange specifications | PL Plate Flat Welding SO Neck Flat Welding WN Neck Flat Welding The number represents the flange diameter. For example: 100=DN100 |
| ④ Form of flange sealing surface | RF convex surface FF full plane RJ ring connection surface MFM concave convex surface TG tenon groove surface |
| ⑤ Flange standard | HG - Ministry of Chemical Industry Standard DIN - German Standard JIS - Japanese Standard GB - National Standard ANSI - American Standard |
| ⑥ Pressure rating of filter pipe flange | For example: P06=PN6 |
| ⑦ Filter filtration accuracy | For example: 5=5 μ m |
| ⑧ Internal and external surface treatment of filters | A-sandblasting B-polishing C-electrolysis D-painting E-spraying epoxy resin F-phosphating J-degreasing |
| A/b=sandblasting on the outer surface/polishing on the inner surface | |
| ⑨ Filter flow direction selection, for example: T8=TYPE8 | |
| Zhuo Nuo Filter Bag Performance Table | ||||
| Filter bag series | 材质 Material | Filter type | 通用型号 Universal model | Filtering accuracy |
| Standard filter bag | PO/PE/NMO | Relative and absolute filtering | 1#/2#/3#/4#/5# | 0.5~ 1000 |
| Durable needle felt filter bag | PP/PE/PTFE | Deep relative filtration | 1#/2#/3#/4#/5# | 0.5~2000 |
| Durable mesh filter bag | NMO/PP/PE | Surface relative filtration | 1#/2#/3#/4#/5# | 25~2000 |
| Multi layer high-efficiency filter bag | PP/PE | Deep relative filtration | 1#/2# | 0.2~50 |
| Absolute Precision Filter Bag | PP/PE | Deep absolute filtering | 1#/2# | 0.2~50 |
| Ultra long lifespan filter bag | PP/PE | Surface relative filtration | 1#/2# | 0.2~50 |
| Activated carbon filter bag | PP/PE | Deep adsorption filtration | 1#/2#/5# | 1~100 |
| Oil absorption filter bag | PP | Deep relative filtration | 1#/2#/5# | 1~50 |
| Folding filter bag | PP | Deep absolute filtering | 1#/2# | 1~50 |
| Anode filter bag | PE/PP | Surface relative filtration | 非标定制 | 50~200 |
Product Categories : Filter Core Components > Filter Bag
