Our high-strength magnetism is easy to clean
Embedded grid provides unparalleled horizontal pollutant removal, removing submicron iron and quasi magnetism
From the most demanding and challenging process environment.
This unit contains a high-strength magnetic grille that is easy to clean. The grille is produced around a food grade seal by a three cone locking nut that ensures uniform pressure.
It is common to install many units throughout the entire processing facility to ensure that pollutants are removed at the source of generation.
All dry powder and granular materials can be processed through this unit. Electrical safety interlocks can be installed on the grid to stop the process
Unexpectedly opened.
The ZMC-Q Magnetic easy clean
Filter - Quadruple is a state-of-the-art filtration system designed for efficient and effective removal of ferrous particles from various liquids. This system is part of the Anitary Magnetic Traps and Liquids Magnetic Traps family, which are engineered to meet the highest standards of cleanliness and hygiene, making them ideal for applications in the food and beverage industry as well as other sectors where purity is crucial.
The ZMC-Q features a quadruple design, which means it has four magnetic poles, significantly enhancing its ability to capture and hold contaminants. This design ensures a broader magnetic field coverage, leading to improved filtration efficiency compared to single or double pole filters.
For maintenance, the ZMC-Q is equipped with a manually cleaned magnetic trap, which simplifies the cleaning process. Users can easily access the magnetic components to remove trapped particles, ensuring the system remains in optimal working condition without the need for complex automated cleaning mechanisms.
In summary, the ZMC-Q Magnetic easy clean filter - Quadruple is a robust and reliable choice for any facility that requires the highest level of liquid purity. Its combination of powerful magnetic filtration and user-friendly maintenance features make it a preferred solution for Anitary and Liquids Magnetic Traps applications.
Benefifits
• Easy to clean
• Removes micron sized contaminants
• High collection capacity
• Reduces 'spark' risk
Performance
Magnetic Performance 7000, 9000, 10000
Performance Reading On tube surface
Magnet Grade N35 & N45 – Inspected and confifirmed via hysterograph
prior to use
Temperature
-20°C / +90°C
Pressure
+ / - 0.2 Bar
Suitability
Suitable Products Dry powders and granulates
Suitable Location Inlet / outlet points, pre- / post-silo and machinery points
Materials
Magnetic Material Rare Earth Neodymium Iron Boron - (NdFeb)
Housing
316 grade stainless steel
Tubing
316 grade stainless steel
Sealing
Self adhered white foam
Tri-cone Nuts
Stainless Steel
Surface Finish
Brushed internally / Polished externally to 0.6μm
Cleaning
When the unit requires cleaning, simply remove the outer grid securing tri-cone
locking nuts and remove the grid from the housing. Remove the central tri-cone
locking nut and separate the grid assembly allowing all attracted contamination to
simply fall away.
Options
• Stainless Steel Toggle Clamps • Larger sizes available
• Pharmaceutical specifification • Safety relay switches
• Metal Detectable Seal
• Higher temperature versions available
